Cell Signaling Technology

Product Pathways - Protein Translation

Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb #4858

ps6

No. Size Price
4858L 300 µl ( 60 western blots ) ¥9,458.00 现货查询 购买询价
4858S 100 µl ( 20 western blots ) ¥4,050.00 现货查询 购买询价
4858T 20 µl ( 2 western blots ) ¥1,600.00 现货查询 购买询价
4858 carrier free & custom formulation / quantityemail request
Applications Dilution Species-Reactivity Sensitivity MW (kDa) Isotype
W 1:2000 Human,Mouse,Rat,Monkey,Mink,S. cerevisiae, Endogenous 32 Rabbit IgG
IHC-P 1:400
F 1:25
IF-IC 1:100
IHC-F 1:400

Species cross-reactivity is determined by western blot.

Applications Key: W=Western Blotting, IHC-P=Immunohistochemistry (Paraffin), F=Flow Cytometry, IF-IC=Immunofluorescence (Immunocytochemistry), IHC-F=Immunohistochemistry (Frozen),

Homology

Species predicted to react based on 100% sequence homology: Chicken, Pig,

Specificity / Sensitivity

Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb detects endogenous levels of ribosomal protein S6 only when phosphorylated at Ser235 and 236.

Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗检测仅在丝氨酸235和236位点磷酸化的内源性核糖体蛋白S6水平。

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic phosphopeptide corresponding to residues surrounding Ser235 and Ser236 of human ribosomal protein S6.

通过人工合成人源核糖体蛋白S6蛋白Ser235和Ser236位点周围相应的磷酸化片段去免疫动物从而制备单克隆抗体。

IF-IC

IF-IC

Confocal immunofluorescent analysis of HeLa cells, rapamycin-treated (left) or 20% serum-treated (right), using Phospho-S6 Ribosomal protein (Ser235/Ser236) (D57.2.2E) XP® Rabbit mAb (green). Actin filaments have been labeled with Alexa Fluor® 555 phalloidin (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

使用Phospho-S6 Ribosomal protein (Ser235/Ser236) (D57.2.2E) XP® Rabbit mAb兔单抗(绿色),共聚焦免疫荧光观察磷酸化S6核糖体蛋白在HeLa细胞中定位,分为rapamycin处理组(左图)和20% 血清处理组(右图)。Alexa Fluor® 555 phalloidin标记微丝蛋白(红色)。蓝色伪彩= DRAQ5® #4084 (DNA荧光染料)。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析小鼠脾脏组织石蜡切片。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded A549 xenograft, untreated (left) or λ phosphatase-treated (right), using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析A549异种移植物石蜡切片,分为对照组(左图)和λ磷酸酶处理组(右图)。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded LNCaP cells, untreated (left) or rapamycin-treated (right), using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析LNCaP细胞石蜡切片,分为对照组(左图)和rapamycin对照组(右图)。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析人类结肠癌石蜡切片。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb in the presence of control peptide (left) or Phospho-S6 Ribosomal Protein (Ser235/236) Blocking Peptide #1220 (right).

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析人类乳腺癌组织石蜡切片,分别孵育对照多肽(左图)和Phospho-S6 Ribosomal Protein (Ser235/236) Blocking Peptide #1220 (右图)。

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Jurkat cells, untreated (green) or treated with LY294002, wortmannin and U0126 (blue), using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb compared to a nonspecific negative control antibody (red).

与非特异阴性对照抗体 (红色)比较,使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb,流式细胞术分析Jurkat细胞,细胞分为未处理组(绿色)和LY294002、Wortmannin和U0126处理组(蓝色)。

Western Blotting

Western Blotting

Western blot analysis of extracts from PC12 and NIH/3T3 cells, treated with λ phosphatase, 20% FBS (20 min) or 100 ng/ml PDGF (20 min) as indicated, using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb (upper) or S6 Ribosomal Protein (5G10) Rabbit mAb #2217 (lower).

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗 (上图)和S6 Ribosomal Protein (5G10) Rabbit mAb兔单抗 #2217 (下图),免疫印迹(Western Blot)分析在NIH/3T3细胞系中磷酸化S6核糖体蛋白(Ser235/236)和S6核糖体蛋白 (5G10)的水平,如图所示分别给予λ磷酸酶、20% FBS (20分钟)和100 ng/ml PDGF (20分钟)处理。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析人类肺癌组织石蜡切片。

IHC-F (frozen)

IHC-F (frozen)

Immunohistochemical analysis of frozen U-87MG xenograft using Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb.

使用Phospho-S6 Ribosomal Protein (Ser235/236) (D57.2.2E) XP® Rabbit mAb兔单抗,免疫组化分析U-87MG 异种移植物的冰冻切片。

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis using Phospho-S6 Ribosomal Protein (S235/236) (D57.2.2E) XP® Rabbit mAb on SignalSlide® Phospho-Akt (Ser473) IHC Controls #8101 (paraffin-embedded LNCaP cells, untreated (left) or LY294002-treated (right).

Background

One way that growth factors and mitogens effectively promote sustained cell growth and proliferation is by upregulating mRNA translation (1,2). Growth factors and mitogens induce the activation of p70 S6 kinase and the subsequent phosphorylation of the S6 ribosomal protein. Phosphorylation of S6 ribosomal protein correlates with an increase in translation of mRNA transcripts that contain an oligopyrimidine tract in their 5' untranslated regions (2). These particular mRNA transcripts (5'TOP) encode proteins involved in cell cycle progression as well as ribosomal proteins and elongation factors necessary for translation (2,3). Important S6 ribosomal protein phosphorylation sites include several residues (Ser235, Ser236, Ser240, and Ser244) located within a small, carboxy-terminal region of the S6 protein (4,5).

生长因子和有丝分裂原有效促进维持细胞生长和增殖的一个方面就是通过上调mRNA翻译(1,2)。生长因子和有丝分裂原能诱导p70 S6激酶的激活和随后S6核糖体蛋白的磷酸化。S6核糖体蛋白的磷酸化与mRNA转录本的翻译增加有关,而这个mRNA转录本是在5端非翻译区含有一个寡嘧啶区(2)。这些特殊的mRNA转录本 (5'TOP) 能够编码涉及细胞周期进程的蛋白质如翻译必须的核糖体蛋白和延伸因子(2,3)。重要的S6核糖体蛋白的磷酸化位点包含数个定位在S6蛋白一个小的羧基末端区域残基(Ser235, Ser236, Ser240, and Ser244) (4,5)。

  1. Dufner, A. and Thomas, G. (1999) Exp Cell Res 253, 100-9.
  2. Peterson, R.T. and Schreiber, S.L. (1998) Curr Biol 8, R248-50.
  3. Jefferies, H.B. et al. (1997) EMBO J 16, 3693-704.
  4. Ferrari, S. et al. (1991) J Biol Chem 266, 22770-5.
  5. Flotow, H. and Thomas, G. (1992) J Biol Chem 267, 3074-8.

Application References

Have you published research involving the use of our products? If so we'd love to hear about it. Please let us know!

Protocols

Companion Products


For Research Use Only. Not For Use In Diagnostic Procedures.

DRAQ5 is a registered trademark of Biostatus Limited.

Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.

XP is a registered trademark of Cell Signaling Technology, Inc.

Alexa Fluor is a registered trademark of Life Technologies Corporation.

Cell Signaling Technology® is a trademark of Cell Signaling Technology, Inc.
