Cell Signaling Technology

Product Pathways - Lymphocyte Signaling

PD-L1 (E1L3N®) XP® Rabbit mAb #13684

B7-H1   B7H1   CD274   PD1   PDCD1 Ligand 1   Programmed cell death 1 ligand 1

No. Size Price
13684S 100 µl ( 10 western blots ) ¥7,500.00 现货查询 购买询价
13684T 20 µl ( 2 western blots ) ¥2,000.00 现货查询 购买询价
13684 carrier free & custom formulation / quantityemail request
Applications Dilution Species-Reactivity Sensitivity MW (kDa) Isotype
W 1:1000 Human, Endogenous 40-50 Rabbit IgG
IP 1:50
IHC-P 1:200
F 1:400

Species cross-reactivity is determined by western blot.

Applications Key: W=Western Blotting, IP=Immunoprecipitation, IHC-P=Immunohistochemistry (Paraffin), F=Flow Cytometry,

Specificity / Sensitivity

PD-L1 (E1L3N) XP® Rabbit mAb recognizes endogenous levels of total PD-L1 protein.

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to residues near the carboxy terminus of human PD-L1 protein.

Western Blotting

Western Blotting

Western blot analysis of extracts from A549 cells, IFN-γ treated (100 ng/mL, 48 hr; +) or untreated (-), using PD-L1 (E1L3N™) XP® Rabbit mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from KARPAS-299, SUP-M2, and PC-3 cells using PD-L1 (E1L3N™) XP® Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of untreated SUP-M2 cells using PD-L1 (E1L3N™) XP® Rabbit mAb (blue) compared to concentration matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (red). Anti-rabbit IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 647 Conjugate) #4414 was used as a secondary antibody.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded Karpas-299 (left) or PC-3 (right) cell pellets using PD-L1 (E1L3N™) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma using PD-L1 (E1L3N™) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human placenta using PD-L1 (E1L3N™) XP® Rabbit mAb in the presence of control peptide (left) or antigen-specific peptide (right).

Background

Programmed cell death 1 ligand 1 (PD-L1, B7-H1, CD274) is a member of the B7 family of cell surface ligands that regulate T cell activation and immune responses. The PD-L1 ligand binds the PD-1 transmembrane receptor and inhibits T cell activation. PD-L1 was discovered following a search for novel B7 protein homologs and was later shown to be expressed by antigen presenting cells, activated T cells, and tissues including placenta, heart, and lung (1-3). Similar in structure to related B7 family members, PD-L1 protein contains extracellular IgV and IgC domains and a short, cytoplasmic region. Research studies demonstrate that PD-L1 is expressed in several tumor types, including melanoma, ovary, colon, lung, breast, and renal cell carcinomas (4-6). Expression of PD-L1 in cancer is associated with tumor infiltrating lymphocytes, which mediate PD-L1 expression through the release of interferon gamma (7). Additional research links PD-L1 expression to cancers associated with viral infections (8,9).

  1. Dong, H. et al. (1999) Nat Med 5, 1365-9.
  2. Freeman, G.J. et al. (2000) J Exp Med 192, 1027-34.
  3. Liang, S.C. et al. (2003) Eur J Immunol 33, 2706-16.
  4. Dong, H. et al. (2002) Nat Med 8, 793-800.
  5. Thompson, R.H. et al. (2006) Cancer Res 66, 3381-5.
  6. Pardoll, D.M. (2012) Nat Rev Cancer 12, 252-64.
  7. Taube, J.M. et al. (2012) Sci Transl Med 4, 127ra37.
  8. Lyford-Pike, S. et al. (2013) Cancer Res 73, 1733-41.
  9. Chen, B.J. et al. (2013) Clin Cancer Res 19, 3462-73.
  10. Wimberly, H. et al. (2014) Cancer Immunol Res , .

Application References

Have you published research involving the use of our products? If so we'd love to hear about it. Please let us know!

Protocols

Companion Products


For Research Use Only. Not For Use In Diagnostic Procedures.

DRAQ5 is a registered trademark of Biostatus Limited.

Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.

XP is a registered trademark of Cell Signaling Technology, Inc.

SignalStain is a trademark of Cell Signaling Technology, Inc.

Alexa Fluor is a registered trademark of Life Technologies Corporation.

Tween is a registered trademark of ICI Americas, Inc.

E1L3N is a registered trademark of Cell Signaling Technology, Inc.

Cell Signaling Technology® is a trademark of Cell Signaling Technology, Inc.
